Freightliner Heavy Duty AM/FM Stereo with Bluetooth, USB and Weather Band

The PP107217 is the Freightliner match to the Aptiv PP107200: a heavy-duty AM/FM/Weather Band radio with a front 3.5mm aux jack, front USB, and built-in Bluetooth. No extras — just a durable head unit for a commercial cab. It is made for Freightliner trucks 2017 and newer with the digital instrument panel, so it works with the newer dash display and steering wheel controls. On those trucks the factory harness plugs straight in. Older Freightliners should use a standard Aptiv model instead, such as the PP107200.

This unit is for 2017-and-newer Freightliner Cascadia cabs with the digital cluster. Trucks built without a factory radio may need a dealer to turn on steering wheel and instrument-cluster parameters. Install it in an older Freightliner and those controls may not work.

Built-in Bluetooth® profile is selectable between Audio Streaming and/or Hands-Free phone operation. Utilizing the vehicle's audio system and a remote mic* - up to 10 devices can be easily stored in the radio memory for fast pairing. Supports Dual Bluetooth Connections — connect one bluetooth device for hands-free calling and another for audio streaming.

Front Panel USB Port - gives a direct connect location for memory devices with USB interface, to play stored music and/or charge the device (2.1 amps). The USB also allows iPod control through the radio front panel buttons.

Main Features:

• AM/FM and Weather Band Receiver
• Built-in Bluetooth®
• Front 3.5mm Audio Input
• Front Panel USB Port
• PA Function (PA Mic & Cable sold separately)
• White Backlight Display
• Amber Illuminated Buttons
• Retains Steering Wheel and Sleeper Controls

Aptiv Brand Common Features:

• HEAVY-DUTY DESIGN – made for a commercial vehicle driver by having larger buttons and a heavy-duty construction for tougher environments.
• SAE J1455 COMPLIANT – meets all the test standards for reliability of an electronic component in a commercial vehicle.
• WEATHER BAND (WB) – offers National Weather Radio Broadcasts from over 1,025 locations throughout the United States on seven VHF/FM frequencies free-of-charge to provide continuous weather information 24 hours a day. Range: 162.400 MHz – 162.550 MHz
• ISO CONNECTOR – allows the radio to be connected directly to the vehicle's harness; no additional harness is required – no cutting, no separate accessories to purchase for all commercial vehicles manufactured with the ISO connect harness.
• FRONT AUX INPUT (MUSIC PORT) – easy access to plug in a smart device and enjoy your digital music library through the vehicle's speakers.
• REAR AUX INPUT – provides an auxiliary terminal for permanent hard wire to the rear side of the radio.
• SAE J1939 COMPLIANT – allows the different vehicle components that run on the communication bus system to talk to each other, compatible with most digital steering wheel/rear-sleeper controls.
• QUARTZ ALARM CLOCK – convenient, built-in quartz alarm clock with one hour timer.
• OUTPUT POWER – 18 Watts x 4 Channels (72 Watts)
• SOUND QUALITY (EQ) FUNCTION – select the sound type (Pop, Rock, Country, News, Jazz, Classical or Manual) to improve the dynamic range
• MANUAL BASS, MID, TREBLE (EQ) FUNCTION - Adjust the sound to your individual liking without relying on factory audio EQ presets.
• BALANCE AND FADER CONTROL - Allows driver to customize audio even further.
• 6 AM / 12 FM RADIO PRESET BUTTONS
• AUTO STORE MEMORY
• AUTO BAUD RATE – capable of auto detecting the correct CAN bus baud rate to use at power up; the possible baud rate is 250K or 500K.
• MECHLESS – no Compact Disc (CD) Player
• SHALLOW CHASSIS – 86.5 mm in depth
• VF DOT MATRIX DISPLAY – three line display that maximizes the viewing area on the front of the radios. This allows for more information on the screen and minimizes the need to scroll.
• WHITE FAKRA AM/FM ANTENNA CONNECTOR – robust locking mechanism, small form factor with high speed capability which allows for better cable management.
• MOTOROLA TO FAKRA ADAPTER CABLE – AM/FM Radio Antenna Adapter Fakra Jack code B to Motorola DIN socket connector six-inch cable. Adapter cable included with each APTIV radio model until OEM truck manufacturers change wiring from Motorola to FAKRA.
